Description
- Laser Scanning Parameters
- Point Frequency: Single return 320,000 pts/s, Dual return 640,000 pts/s
- Measurement Range: 120 m or 300 m
- Field of View: 360° x 270°
- Measurement Accuracy: <5cm
- Relative Accuracy: 1cm
- General Parameters
- Weight: <1.85 kg (exclude battery and GCP benchmark)
- Battery Endurance: 180 minutes
- Battery Capacity: 70.56 Wh
- Storage Capacity: 1TB
- Protection Rating: IP54
- Operating Temperature: -20℃ to 55℃
- Storage Temperature: -25℃ to 60℃
- Imaging Parameters
- Image Resolution: 2592(H) x 1944(V)
- Camera Field of View: 135° x 100°
- Mapping and Processing
- Mapping Modes: SLAM, SLAM-RTK, PPK
- Real-time Processing: Real-time Solution, Real-time Coloring, Accuracy Heatmap
- GNSS and Positioning
- RTK Protocol: NTRIP
- Supported Satellite Systems:
- BDS B1, B2, B3, B1C, B2a, B2b
- GPS L1C/A, L1C, L2P(Y), L2C, L5
- GLONASS L1, L2
- Galileo E1, E5a, E5b, E6
- QZSS L1, L2, L5, L6
- IRNSS L5
- SBAS L1, L2, L5
